Item: Outdoor LED Screen:
Application: Shopping Centers, Building Wall, Billboards, Outdoor Advertising.
Certificates: FCC, CE, EMC, LVD.
Services: 5 Years Warranty
None
PRODUCT DESCRIPTION
| Outdoor Fixed LED Screen Specification | |||||||||||
| Item | I Series Fixed | I Series Fixed | I Series Fixed | I Series Fixed | I Series Fixed | ||||||
| Pixe Pictch | 4mm | 5mm | 6mm | 8mm | 10mm | ||||||
| Led encapsulation | SMD1921 | SMD2727 | SMD2727 | SMD3535 | SMD3535 | ||||||
| Scan Mode | 1/8 Scan | 1/8 Scan | 1/8 Scan | 1/4 Scan | 1/2 Scan | ||||||
| Pixe Per Sq.m | 62,500 Pixel | 40,000 Pixel | 27,777 Pixel | 15,625 Pixel | 10,000 Pixel | ||||||
| Module Size(W*H) | 256*128mm | 160*160mm | 192*192mm | 256*128mm | 320*160mm | ||||||
| Cabinet Size(W*H*D) | 1024*768mm | 960*960mm | 960*960mm | 1024*768mm | 960*960mm | ||||||
| Cabinet Weight | 45KG/Pieces | 55KG/Pieces | 40KG/Pieces | 45KG/Pieces | 50KG/Pieces | ||||||
| Max Power Consumption | 1200Watt/㎡ | 1000Watt/㎡ | 1000Watt/㎡ | 800Watt/㎡ | 750Watt/㎡ | ||||||
| Brightness(Nits/㎡) | 5500Nits | 5500Nits | 6000Nits | 6500Nits | 8000Nits | ||||||
| Maintenance methods | Rear Service | ||||||||||
| Cabinet Material | Steel | ||||||||||
| Refresh Rate | 1920hz | ||||||||||
| Color temperature | 6500K ±500（Adjustable） | ||||||||||
| Grey Scale | 14-16bits | ||||||||||
| Average Power Consumption | 500Watt/㎡ | ||||||||||
| IP Protection | IP65 Front/Rear | ||||||||||
| Operating Temperature | -40°C to 50°C | ||||||||||
| Working Voltage | 110-240Volt(50-60hz) | ||||||||||
