Item: 500*500 Outdoor LED Display.
Applications: Outdoor Events, Concerts, Sport Events, Festivals.
Certificates: FCC, CE, EMC, LVD.
Services: 5 Years Warranty
None
PRODUCT DESCRIPTION
16 Bit Image Processing
Black Face SMD
Electromagnetic Compatibility(EMC
Fan-less
Fast Installation
Front Serviceable, Easy Access
Heat Dissipation
High Accuracy Of Installation, Diecast System
High Brightness
High End Components
High Refresh Rate
ISO9001 Certification
Light Weight
Low Power Consumption
No Flicker on Camera
Outdoor
Portable
Seamless Display
Ultrathin Module
Wide Viewing Angle
| Outdoor Rental LED Screen Specification | ||||||||||
| Item | V Series | V Series | V Series | |||||||
| Pixe Pictch | 3.91mm | 4.81mm | 5.95mm | |||||||
| Led encapsulation | SMD1921 | SMD2727 | SMD2727 | |||||||
| Scan Mode | 1/8 Scan | 1/13 Scan | 1/7 Scan | |||||||
| Pixe Per Sq.m | 65,536 Pixel | 43,264 Pixel | 28,224Pixel | |||||||
| Maintenance methods | Rear Service | |||||||||
| Cabinet Material | Die Casting Aluminum | |||||||||
| Module Size(W*H) | 250*250mm | |||||||||
| Cabinet Size(W*H*D) | 500*500*80mm | |||||||||
| Refresh Rate | 3840hz | |||||||||
| Color temperature | 7000K ±500（Adjustable） | |||||||||
| Grey Scale | 14-16bits | |||||||||
| Cabinet Weight | 9KG/Pieces | |||||||||
| Brightness(Nits/㎡) | 5500-6000nits | |||||||||
| Average Power Consumption | 350-400Watt/㎡ | |||||||||
| Max Power Consumption | 950Watt/㎡ | |||||||||
| IP Protection | IP65 Front/IP54 Rear | |||||||||
| Operating Temperature | -20°C to 50°C | |||||||||
| Working Voltage | 110-240Volt(50-60hz) | |||||||||
